Reference Manual
00809-0100-4809, Rev DA
Appendix A: Specifications and Reference Data
September 2015
89
Specifications and Reference Data
Line size D 1-7
420 42-in. (1066 mm) • •
480 48-in. (1210 mm) • •
600 60-in. (1520 mm) • •
720 72-in. (1820 mm) • •
780 78-in (1950 mm) • •
840 84-in. (2100 mm) • •
900 90-in. (2250 mm) • •
960 96-in. (2400 mm) • •
Pipe I.D. range
(1)
C Range C from the Pipe I.D. table • • ★
D Range D from the Pipe I.D. table • • ★
A Range A from the Pipe I.D. table • •
B Range B from the Pipe I.D. table • •
E Range E from the Pipe I.D. table • •
Z Non-standard Pipe I.D. range or line sizes greater than 12-in. (300 mm) • •
Pipe material/Mounting assembly material
C Carbon steel (A105) • • ★
S 316 Stainless Steel • • ★
0
(2)
No mounting (customer supplied) • • ★
G Chrome-Moly Grade F-11 • •
N Chrome-Moly Grade F-22 • •
J Chrome-Moly Grade F-91 • •
Piping orientation
H Horizontal piping • • ★
D Vertical piping with downwards flow • • ★
U Vertical piping with upwards flow • • ★
Annubar type
P Pak-Lok • • ★
Table 1. Rosemount 3051SFA Annubar Flowmeter Ordering Information
★ The Standard offering represents the most common options. The starred options (★) should be selected for best delivery.
__The Expanded offering is subject to additional delivery lead time.
