Rosemount 8712 - Rosemount 8712 E Ordering Information; Code Transmitter Power Supply; Code Conduit Entry; Code Safety Approvals

Reference Manual
00809-0100-4664, Rev BA
January 2010
A-9
Rosemount 8712
ROSEMOUNT 8712E ORDERING INFORMATION
Model Product Description
8712E Remote Magnetic Flowmeter Transmitter
Code Transmitter Style
S Standard
Code Transmitter Mount
R Remote Mount for 2 in. pipe or panel (includes CS mounting bolts and 316L SST bracket)
Code Transmitter Power Supply
1 AC Power Supply (90 to 250 V AC, 50-60Hz)
2 DC Power Supply (12 to 42 V DC)
Code Outputs
A 4-20 mA Digital Electronics (HART Protocol)
Code Conduit Entry
1
1
/2 - 14 NPT, 4 Conduit Entries
2 CM20, 4 Conduit Entries
(1)
3 PG 13.5, 4 Conduit Entries
(2)
Code Safety Approvals
(2)
NA CE Marking, no hazardous location approval
FM & CSA
N0 FM Class 1 Div 2 for non-flammable: CSA Class 1 Div 2
N5 FM Class 1 Div 2 for flammable fluids
ATEX
N1 ATEX Type n Ex nA nL IIC and ATEX Dust Approval
(3)
ND ATEX Dust Approval
IECEx
N7 IECEx Type n Ex nA nL IIC and IECEx Dust Approval
(3)
NF IECEx Dust Approval
Code Options
PlantWeb Product/Process Diagnostics
DA1 Magmeter HART Diagnostic Suite 1: Includes High Process Noise and Ground/Wiring Fault Detection
DA2 Magmeter HART Diagnostic Suite 2: Includes 8714i Meter Verification
Other Options
C1 Custom Configuration (CDS Required)
D1 High Accuracy Calibration (0.15% of rate for matched sensor and transmitter)
(4)
DT Heavy Duty Tagging
M4 Local Operator Interface
B6 316L Stainless Steel 4-bolt Kit for 2-in. Remote Pipe Mount
GE M12, 4-Pin, Male Connector (Eurofast)
GM A Size Mini, 4-Pin, Male Connector (Minifast)
