Reference Manual
00809-0100-4664, Rev BA
January 2010
4-7
Rosemount 8712
Total Low Limit
Set the net total value that corresponds to the low limit set point for the Flow
Limit 1 alert.
Total Limit Hysteresis
Set the hysteresis band for the total limit to determine how quickly the
transmitter comes out of Alert status.
Advanced Diagnostics The advanced diagnostics menu contains information on all of the additional
diagnostics and tests that are available in the 8712 transmitter if one of the
diagnostics suite packages was ordered.
Rosemount offers two advanced diagnostic suites. Functionality under this
menu will depend on which of these suites are ordered.
Advanced diagnostics suite option one (DA1 option) contains advanced
diagnostics for High Process Noise detection and Grounding and Wiring fault
detection.
Advanced diagnostics suite option two (DA2 option) contains advanced
diagnostics for the 8714i Meter Verification. This diagnostic is used to verify
the accuracy and performance of the magnetic flowmeter installation.
8714i Meter Verification
This diagnostic allows you to test and verify that the sensor, transmitter, or
both are working within specifications. For more details on this diagnostic, see
Appendix C: "Diagnostics".
Run 8714i
Run the meter verification test to check the transmitter, sensor, or entire
installation.
Full Meter Verification
Run the internal meter verification to validate the entire installation, sensor
and transmitter at the same time.
Transmitter Only
Run the internal meter verification to validate the transmitter only.
Sensor Only
Run the internal meter verification to validate the sensor only.
Field Comm. 1, 2, 2, 8, 4
Field Comm. 1, 2, 2, 8, 5
Field Comm. 1, 2, 3
Field Comm. 1, 2, 3, 1
LOI Key AUX. FUNCTION
Field Comm. 1, 2, 3, 1, 1
LOI Key AUX. FUNCTION
Field Comm. 1, 2, 3, 1, 1, 1
Field Comm. 1, 2, 3, 1, 1, 2
Field Comm. 1, 2, 3, 1, 1, 3
