Reference Manual
00809-0100-4664, Rev BA
January 2010
Rosemount 8712
5-6
Figure 5-6. Rosemount 8711
Mounting Position
Flow Direction The sensor should be mounted so that the FORWARD end of the flow arrow,
shown on the sensor identification tag, points in the direction of flow through
the tube (see Figure 5-7).
Figure 5-7. Flow Direction
45° Electrode Plane
45° Electrode Plane
