Reference Manual
00809-0100-4664, Rev BA
January 2010
Rosemount 8712
4-8
8714i Results
Review the results of the most recently performed 8714i Meter Verification
test. Information in this section details the measurements taken and if the
meter passed the verification test. For more details on these results and what
they mean, see Appendix C: "Diagnostics".
Test Condition
Displays the conditions that the 8714i Meter Verification test was performed
under. For more details on this parameter see Appendix C: "Diagnostics".
Test Criteria
Displays the criteria that the 8714i Meter Verification test was performed
against. For more details on this parameter see Appendix C: "Diagnostics".
8714i Test Result
Displays the results of the 8714i Meter Verification test as pass or fail. For
more details on this parameter see Appendix C: "Diagnostics".
Simulated Velocity
Displays the test velocity used to verify transmitter calibration. For more
details on this parameter see Appendix C: "Diagnostics".
Actual Velocity
Displays the velocity measured by the transmitter during the transmitter
calibration verification test. For more details on this parameter see
Appendix C: "Diagnostics".
Velocity Deviation
Displays the deviation of the transmitter calibration verification test. For more
details on this parameter see Appendix C: "Diagnostics".
Transmitter Calibration Test Result
Displays the result of the transmitter calibration verification test as pass or fail.
For more details on this parameter see Appendix C: "Diagnostics".
Sensor Calibration Deviation
Displays the deviation of the sensor calibration verification test. For more
details on this parameter see Appendix C: "Diagnostics".
Sensor Calibration Test Result
Displays the result of the sensor calibration verification test as pass or fail. For
more details on this parameter see Appendix C: "Diagnostics".
Field Comm. 1, 2, 3, 1, 2
LOI Key XMTR INFO
Field Comm. 1, 2, 3, 1, 2, 1
Field Comm. 1, 2, 3, 1, 2, 2
Field Comm. 1, 2, 3, 1, 2, 3
Field Comm. 1, 2, 3, 1, 2, 4
Field Comm. 1, 2, 3, 1, 2, 5
Field Comm. 1, 2, 3, 1, 2, 6
Field Comm. 1, 2, 3, 1, 2, 7
Field Comm. 1, 2, 3, 1, 2, 8
Field Comm. 1, 2, 3, 1, 2, 9
