Rosemount 8712 - Page 51

Reference Manual
00809-0100-4664, Rev BA
January 2010
4-13
Rosemount 8712
8714i Test Result
Displays the results of the 8714i Meter Verification test as pass or fail. For
more details on this parameter see Appendix C: "Diagnostics".
Simulated Velocity
Displays the test velocity used to verify transmitter calibration. For more
details on this parameter see Appendix C: "Diagnostics".
Actual Velocity
Displays the velocity measured by the transmitter during the transmitter
calibration verification test. For more details on this parameter see
Appendix C: "Diagnostics".
Velocity Deviation
Displays the deviation of the transmitter calibration verification test. For more
details on this parameter see Appendix C: "Diagnostics".
Transmitter Verification Test Result
Displays the result of the transmitter calibration verification test as pass or fail.
For more details on this parameter see Appendix C: "Diagnostics".
Sensor Verification Deviation
Displays the deviation of the sensor calibration verification test. For more
details on this parameter see Appendix C: "Diagnostics".
Sensor Verification Result
Displays the result of the sensor calibration verification test as pass or fail. For
more details on this parameter see Appendix C: "Diagnostics".
Coil Circuit Test Result
Displays the result of the coil circuit test as pass or fail. For more details on
this parameter see Appendix C: "Diagnostics".
Electrode Circuit Test Result
Displays the result of the electrode circuit test as pass or fail. For more details
on this parameter see Appendix C: "Diagnostics".
NOTE
To access the coil circuit test result and electrode circuit test result, you must
scroll to this option in the HART Field Communicator.
Field Comm. 1, 2, 3, 7, 3
Field Comm. 1, 2, 3, 7, 4
Field Comm. 1, 2, 3, 7, 5
Field Comm. 1, 2, 3, 7, 6
Field Comm. 1, 2, 3, 7, 7
Field Comm. 1, 2, 3, 7, 8
Field Comm. 1, 2, 3, 7, 9
Field Comm. 1, 2, 3, 7, 10
Field Comm. 1, 2, 3, 7, 11
