Rosemount 8712 - Page 79

Reference Manual
00809-0100-4664, Rev BA
January 2010
4-41
Rosemount 8712
Sensor Cal Test Result 1,2,3,1,2,9
Coil Circuit Test Result 1,2,3,1,2,x
Electrode Circuit Test Result 1,2,3,1,2,x
Sensor Signature 1,2,3,1,3
Signature Values 1,2,3,1,3,1
Coil Resistance 1,2,3,1,3,1,1
Coil Signature 1,2,3,1,3,1,2
Electrode Resistance 1,2,3,1,3,1,3
Re-Signature Meter 1,2,3,1,3,2
Recall Last Saved Values 1,2,3,1,3,3
Set Pass/Fail Criteria 1,2,3,1,4
No Flow Limit 1,2,3,1,4,1
Flowing Limit 1,2,3,1,4,2
Empty Pipe Limit 1,2,3,1,4,3
Measurements 1,2,3,1,5
Coil Resistance 1,2,3,1,5,1
Coil Signature 1,2,3,1,5,2
Electrode Resistance 1,2,3,1,5,3
Licensing 1,2,3,2
License Status 1,2,3,2,1
License Key 1,2,3,2,2
Device ID 1,2,3,2,2,1
License Key 1,2,3,2,2,2
Diagnostic Variables 1,2,4
EP Value 1,2,4,1
Electronics Temp 1,2,4,2
Line Noise 1,2,4,3
5 Hz Signal to Noise Ratio (SNR) 1,2,4,4
37 Hz SNR 1,2,4,5
Signal Power 1,2,4,6
8714i results 1,2,4,7
Test Condition 1,2,4,7,1
Test Criteria 1,2,4,7,2
8714i Test Result 1,2,4,7,3
Simulated Velocity 1,2,4,7,4
Actual Velocity 1,2,4,7,5
Velocity Deviation 1,2,4,7,6
Xmtr Cal Test Result 1,2,4,7,7
Sensor Cal Deviation 1,2,4,7,8
Sensor Cal Test Result 1,2,4,7,9
Coil Circuit Test Result 1,2,4,7,x
Electrode Circuit Test Result 1,2,4,7,x
Trims 1,2,5
D/A Trim 1,2,5,1
Scaled D/A Trim 1,2,5,2
Digital Trim 1,2,5,3
Auto Zero 1,2,5,4
Universal Trim 1,2,5,5
View Status 1,2,6
Basic Setup 1,3
Tag 1,3,1
Flow Units 1,3,2
PV Units 1,3,2,1
Special Units 1,3,2,2
Volume Unit 1,3,2,2,1
Function HART Fast Keys
