Rosemount 8712
4-44
Figure 4-4. Local Operator
Interface (LOI) Data Entry Keys
for the Rosemount 8712
Data Entry Keys Function Performed
Shift
• Moves the blinking cursor on the display one character to the right
• Scrolls through available values
Increment
• Increments the character over the cursor by one
• Steps through all the digits, letters, and symbols that are applicable to the present operation
• Scrolls through available values
Enter Stores the displayed value previously selected with the SHIFT and INCR. keys
Display Control Keys Function Performed
Flow Rate Displays the user-selected parameters for flow indication
Totalize Displays the present totalized output of the transmitter, and activates the Totalizer group of keys
The choices, Forward and Reverse totals or Net and Gross totals, are selected in Auxiliary Functions
Start/Stop Starts the totalizing display if it is stopped, and stops the display if it is running
Read/Reset Resets the net totalizing display to zero if it is stopped, and halts the display if the display is running
Transmitter Parameters
Keys
Function Performed
Tube Cal No. Identifies the calibration number when using Rosemount sensors, or other manufacturers’ sensors calibrated
at the Rosemount factory
Tube Size Specifies the sensor size and identifies the corresponding maximum flow (0.1 - through 80-inch line sizes)
Units Specifies the desired units:
Gal/Min Liters/Min
ImpGal/Min CuMeter/Hr
Ft/Sec Meters/Sec
Special (user defined)
For a complete list of available units, see Table 3-3 on page 3-9
