Rosemount 8800D Series User Manual

Reference Manual
00809-0100-4004, Rev BA
August 2010
Rosemount 8800D
1-2
SAFETY MESSAGES Procedures and instructions in this manual may require special precautions to
ensure the safety of the personnel performing the operations. Refer to the
safety messages, listed at the beginning of each section, before performing
any operations.
SYSTEM DESCRIPTION The Rosemount 8800D Vortex Flowmeter consists of a meter body and
transmitter, and measures volumetric flow rate by detecting the vortices
created by a fluid passing by the shedder bar.
The meter body is installed in-line with process piping. A sensor is located at
the end of the shedder bar and creates an alternating sine wave due to the
passing vortices. The transmitter measures the frequency of the sine waves
and converts it into a flowrate.
This manual is designed to assist in the installation and operation of the
Rosemount 8800D Vortex Flowmeter.
This product is intended to be used as a flowmeter for liquid, gas, or steam applications.
Any use other than for which it was intended may result in serious injury or death.

Rosemount 8800D Series Specifications

General

Type	Vortex Flow Meter
Measurement Principle	Vortex Shedding
Operating Temperature	-40 to 185°F (-40 to 85°C)
Storage Temperature	-40 to 185°F (-40 to 85°C)
Communication Protocols	FOUNDATION Fieldbus
Material	316 stainless steel
Fluid Type	Liquid, Gas, Steam
Line Size	1/2 to 8 inches (15 to 200 mm)
Approvals	ATEX, IECEx, CSA, FM
Output Signal	4-20 mA
Process Connection	Flanged, Wafer, Threaded
Electrical Connection	M20
Protection Rating	IP66
Mounting Style	Wafer, Flanged
