Reference Manual
00809-0100-4004, Rev BA
August 2010
Rosemount 8800D
B-6
Rosemount 8800D With FOUNDATION
™
fieldbus Protocol
North American Certifications
Factory Mutual (FM) Approvals
E5 Explosion-proof for Class I, Division 1, Groups B, C, and D. Dust Ignition-proof for Class II/III,
Division 1, Groups E, F, and G.
Temperature Code T6 (-50°C
Ta
70°C)
Factory Sealed
Enclosure Type 4X
I5 Intrinsically safe for use in Class I, II, III Division 1, Groups A, B, C, D, E, F, G;
Class I, Zone 0, AEx ia IIC T4
Non-incendive for Class I, Division 2, Groups A, B, C, and D.
NIFW (Non-incendive Field Wiring) when installed per Rosemount Drawing 08800-0112
T4 (-50°C to 60°C)
Enclosure Type 4X.
IE FISCO for Class I, Division 1, Groups A, B, C, and D.
FNICO for Class 1 Division 2, Groups A, B, C, and D.
T4 (-50°C to 60°C)
when installed per Rosemount control drawing 08800-0116.
K5 E5 and I5 combination
Canadian Standards Association (CSA) Approvals
E6 Explosion-Proof for Class I, Division 1, Groups B, C, and D;
Dust Ignition-proof for Class II and Class III, Division 1, Groups E, F, and G;
Class I, Zone 1, Ex d[ia] IIC CSA 06.1674267
T6 (-50°C to 70°C)
Factory Sealed
Single Seal.
Enclosure Type 4X.
I6 Intrinsically safe for use in Class I, II, III Division 1, Groups A, B, C, D, E, F, G;
Non-incendive for Class I, Division 2, Groups A, B, C and D
T4 (-50°C to 60°C)
Single Seal.
Enclosure Type 4X.
IF FISCO for Class I, Division 1, Groups A, B, C, and D;
FNICO for Class 1 Division 2, Groups A, B, C, and D.
T4 (-50°C to 60°C).
When installed per Rosemount drawing 08800-0112
Enclosure Type 4X
K6 E6 and I6 combination.
Combination Certifications
KB E5, I5, E6, and I6 Combination
European Certifications
ATEX Intrinsic Safety Certification
I1 Certification No. Baseefa05ATEX0084X
ATEX Marking II 1 G
EEx ia IIC T4 (-60°C
Ta
60°C)
0575
Input Parameters:
U
i
= 30 Vdc
I
i
= 300 mA
P
i
= 1.3 W
C
i
= 0 F
L
i
= 20 H
