Rosemount 8800D
3-2
PV% of Range Percent of Range — The primary variable as a percentage of range
provides a gauge as to where the current measurement of the meter is within
the configured range of the meter. For example, the range may be defined as
0 gal/min to 20 gal/min. If the current flow is 10 gal/min, the percent of range
is 50 percent.
Analog Output Analog Output — The analog output variable provides the analog value for
the primary variable. The analog output refers to the industry standard output
in the 4–20 mA range. Check the analog output value against the actual loop
reading given by a multi-meter. If it does not match, a 4–20 mA trim is
required. See D/A Trim (Digital-to-Analog Trim).
View Other Variables View Other Variables — Allows for the viewing and configuration of other
variables such as flow units, totalizer operation, and pulse output.
Volume Flow
Allows the user to view the current volumetric flow value.
Volume Flow Units
Allows the user to select the volumetric flow units from the available list.
Field Comm. 1, 1, 2
Field Comm. 1, 1, 3
Field Comm. 1, 1, 4
Field Comm. 1, 1, 4, 1, 1
Field Comm. 1, 1, 4, 1
Volumetric Unit HART LCD Display Field Communicator
U.S. Gallons per second GAL/S gal/s
U.S. Gallons per minute GAL/M gal/m
U.S. Gallons per hour GAL/H gal/h
U.S. Gallons per day GAL/D gal/d
Actual Cubic Feet per second ACFS ACFS
Actual Cubic Feet per minute ACFM ACFM
Actual Cubic Feet per hour ACFH ACFH
Actual Cubic Feet per day ACFD ACFD
Standard Cubic Feet per minute SCFM
Standard Cubic Feet per hour SCFH
Barrels per second BBL/S bbl/s
Barrels per minute BBL/M bbl/min
Barrels per hour BBL/H bbl/h
Barrels per day BBL/D bbl/d
Imperial Gallons per second IGAL/S Impgal/s
Imperial Gallons per minute IGAL/M Impgal/min
Imperial Gallons per hour IGAL/H Impgal/h
Imperial Gallons per day IGAL/D Impgal/d
Liters per second L/S L/s
Liters per minute L/MIN L/min
Liters per hour L/H L/h
Liters per day L/D L/D
Actual Cubic Meters per second ACMS ACMS
Actual Cubic Meters per minute ACMM ACMM
Actual Cubic Meters per hour ACMH ACMH
Actual Cubic Meters per day ACMD ACMD
Million Actual Cubic Meters per day MACMD MACMD
Normal Cubic Meters per minute NCMM
Normal Cubic Meters per hour NCMH
Normal Cubic Meters per day NCMD

Rosemount 8800D Series Specifications

General

Type	Vortex Flow Meter
Measurement Principle	Vortex Shedding
Operating Temperature	-40 to 185°F (-40 to 85°C)
Storage Temperature	-40 to 185°F (-40 to 85°C)
Communication Protocols	FOUNDATION Fieldbus
Material	316 stainless steel
Fluid Type	Liquid, Gas, Steam
Line Size	1/2 to 8 inches (15 to 200 mm)
Approvals	ATEX, IECEx, CSA, FM
Output Signal	4-20 mA
Process Connection	Flanged, Wafer, Threaded
Electrical Connection	M20
Protection Rating	IP66
Mounting Style	Wafer, Flanged
