Rosemount 8800D Series User Manual

Reference Manual
00809-0100-4004, Rev BA
August 2010
3-13
Rosemount 8800D
Mating Pipe ID
(Inside Diameter)
The Pipe ID (Inside Diameter) of the pipe adjacent to the flowmeter can
cause entrance effects that may alter flowmeter readings. You must specify
the exact inside diameter of the pipe to correct for these effects. Enter the
appropriate value for this variable.
Pipe ID values for schedule 10, 40, and 80 piping are given in Table 3 -1. If the
piping in your application is not one of these, you may need to contact the
manufacturer for exact Pipe ID.
f
Variable Mapping Allows the user to select which Variables the 8800D will output.
Primary Variable (PV)
Selections for this Variable are Mass Flow, Volumetric Flow, Velocity Flow,
and Process Temperature. The Primary Variable is the variable mapped to the
analog output.
Secondary Variable (SV)
Selections for this Variable include all Variables that can be mapped to PV,
and also Vortex Frequency, Pulse Output Frequency, Totalizer Value,
Calculated Process Density, Electronics Temperature, and Cold Junction (CJ)
Temperature.
Tertiary Variable (TV)
Selections for this Variable are identical to those of the Secondary Variable.
Quaternary Variable (4V)
Selections for this Variable are identical to those of the Secondary Variable.
PV Units Selections for this include all units available for the selection of PV. This will
set the units for the flow rate or process temperature.
Field Comm. 1, 3, 5
Table 3-1. Pipe IDs for Schedule 10, 40, and 80 Piping
Pipe Size
Inches (mm)
Schedule 10
Inches (mm)
Schedule 40
Inches (mm)
Schedule 80
Inches (mm)
½ (15) 0.674 (17.12) 0.622 (15.80) 0.546 (13.87)
1 (25) 1.097 (27.86) 1.049 (26.64) 0.957 (24.31)
1½ (40) 1.682 (42.72) 1.610 (40.89) 1.500 (38.10)
2 (50) 2.157 (54.79) 2.067 (52.50) 1.939 (49.25)
3 (80) 3.260 (82.80) 3.068 (77.93) 2.900 (73.66)
4 (100) 4.260 (108.2) 4.026 (102.3) 3.826 (97.18)
6 (150) 6.357 (161.5) 6.065 (154.1) 5.716 (145.2)
8 (200) 8.329 (211.6) 7.981 (202.7) 7.625 (193.7)
10 (250) 10.420 (264.67) 10.020 (254.51) 9.562 (242.87)
12 (300) 12.390 (314.71) 12.000 (304.80) 11.374 (288.90)
Field Comm. 1, 3, 6
Field Comm. 1, 3, 6, 1
Field Comm. 1, 3, 6, 2
Field Comm. 1, 3, 6, 3
Field Comm. 1, 3, 6, 4
Field Comm. 1, 3, 7

Rosemount 8800D Series Specifications

General

Type	Vortex Flow Meter
Measurement Principle	Vortex Shedding
Operating Temperature	-40 to 185°F (-40 to 85°C)
Storage Temperature	-40 to 185°F (-40 to 85°C)
Communication Protocols	FOUNDATION Fieldbus
Material	316 stainless steel
Fluid Type	Liquid, Gas, Steam
Line Size	1/2 to 8 inches (15 to 200 mm)
Approvals	ATEX, IECEx, CSA, FM
Output Signal	4-20 mA
Process Connection	Flanged, Wafer, Threaded
Electrical Connection	M20
Protection Rating	IP66
Mounting Style	Wafer, Flanged
