Reference Manual
00809-0100-4004, Rev BA
August 2010
Rosemount 8800D
B-8
ATEX Dust Certification
ND Certification No. Baseefa05ATEX0086/3
II 1D Ex tD A20 IP66 T90°C (-20°C
Ta
70°C)
42 VDC Max
K1 E1, I1, N1 and ND Combination
International IECEx Certifications
Intrinsic Safety
I7 Certification No. IECEx BAS 05.0028X
Ex ia IIC T4 (-60°C T
a
60°C)
Input Parameters:
U
i
= 30 Vdc
I
i
= 300 mA
P
i
= 1.3 W
C
i
= 0 F
L
i
= 20 H
SPECIAL CONDITIONS
When fitted with 90V transient suppressors (T1 Option), the equipment is not
capable of passing the 500V isolation test. This must be taken into account
upon installation.
FISCO/FNICO
IG Certification No. IECEx BAS 05.0028X
Ex ia IIC T4 (-60°C T
a
60°C)
Input Parameters:
U
i
= 17.5 Vdc
I
i
= 380 mA
P
i
= 5.32 W
C
i
= 0 F
L
i
10H
Type N Certification
N7 Certification No. IECEx BAS 05.0029X
Ex nC IIC T4 (-40°C T
a
70°C)
Ui = 32 Vdc Max
Flameproof Certification
E7 Certification No. IECEx KEM 05.0017X
Marking Remote Mount:
Transmitter: Ex d [ia] IIC T6 (-50°C T
a
70°C)
Meter Body: Ex ia IIC T6 (-50°C T
a
70°C)
Marking Integral Mount: Ex d [ia] IIC T6
(-50°C T
a
70°C)
V = 32 Vdc Max
Um = 250V
SPECIAL CONDITIONS
When the equipment is installed, particular precautions must be taken to
ensure, taking into account the effect of the process fluid temperature, that the
ambient temperature of the electrical parts of the equipment is comprised
between -50°C and 70°C.
The remote mounted sensor shall only be connected to the transmitter with
the associated cable, supplied by the manufacturer.
K7 E7, I7, and N7 Combination
