Reference Manual
00809-0100-4004, Rev BA
August 2010
B-7
Rosemount 8800D
SPECIAL CONDITIONS FOR SAFE USE (X)
When fitted with 90V transient suppressors (T1 Option), the equipment is not
capable of passing the 500V isolation test. This must be taken into account
upon installation.
ATEX FISCO/FNICO
IA Certification No. Baseefa05ATEX0084X
ATEX Marking II 1 G
EEx ia IIC T4 (-60°C
Ta
60°C)
0575
Input Parameters:
U
i
= 17.5 Vdc
I
i
= 380 mA
P
i
= 5.32 W
C
i
= 0 F
L
i
< 10 H
SPECIAL CONDITIONS FOR SAFE USE (X)
When fitted with 90V transient suppressors (T1 Option), the equipment is not
capable of passing the 500V isolation test. This must be taken into account
upon installation.
ATEX Type N Certification
N1 Certification No. Baseefa05ATEX0085X
ATEX Marking II 3 G
EEx nAnL IIC T4 (-40°C
Ta
70°C)
Input Parameters:
U
i
= 32 Vdc MAX
C
i
= 0 F
L
i
= 20 H
SPECIAL CONDITIONS FOR SAFE USE (X)
When fitted with 90V transient suppressors (T1 Option), the equipment is not
capable of passing the 500V isolation test. This must be taken into account
upon installation.
ATEX Flameproof Certifications
E1 Certification No. KEMA 99ATEX3852X
ATEX Marking Remote Mount:
Transmitter: II 2(1) G
EEx d [ia]IIC T6 (-50°C
Ta
70°C)
Meter Body: II 1 G
EEx ia IIC T6 (-50°C
Ta
70°C)
ATEX Marking Integral Mount: II 1/2 G
EEx d [ia] IIC T6 (-50°C
Ta
70°C)
0575
V = 42 Vdc Max
Um = 250V
SPECIAL CONDITIONS
When the equipment is installed, particular precautions must be taken to
ensure, taking into account the effect of the process fluid temperature, that the
ambient temperature of the electrical parts of the equipment is comprised
between -50°C and 70°C.
The remote mounted sensor shall only be connected to the transmitter with
the associated cable, supplied by the manufacturer.
