Reference Manual
00809-0100-4004, Rev BA
August 2010
Rosemount 8800D
B-2
EUROPEAN PRESSURE EQUIPMENT DIRECTIVE (PED)
Rosemount 8800 Vortex Flowmeter Line Size 40 mm to 300 mm
Certificate Number PED-H-100
0575
Module H Conformity Assessment
Mandatory CE-marking for flowmeters in accordance with Article 15 of the PED can be found on
the flowtube body.
Flowmeter categories I – III use module H for conformity assessment procedures.
Rosemount 8800 Vortex Flowmeter
Line Size 15 mm and 25 mm
Sound Engineering Practice
Flowmeters that are SEP are outside the scope of PED and cannot be marked for compliance
with PED.
HAZARDOUS LOCATION CERTIFICATIONS
Rosemount 8800D with HART Protocol
North American Certifications
Factory Mutual (FM)
E5 Explosion-proof for Class I, Division 1, Groups B, C, and D;
Dust Ignition-proof for Class II/III, Division 1, Groups E, F, and G;
Temp Code T6 (-50°C
Ta
70°C)
Factory Sealed
Enclosure Type 4X.
I5 Intrinsically safe for use in Class I, II, III Division 1, Groups A, B, C, D, E, F, G;
Class I, Zone 0, AEx ia IIC T4
Non-incendive for Class I, Division 2, Groups A, B, C, and D.
NIFW (Non-incendive Field Wiring) when installed per Rosemount Drawing 08800-0112
T4 (-50°C to 70°C)
Enclosure Type 4X.
K5 E5 and I5 Combination
Canadian Standards Association (CSA)
E6 Explosion-Proof for Class I, Division 1, Groups B, C, and D;
Dust Ignition-proof for Class II and Class III, Division 1, Groups E, F, and G;
Class I, Zone 1, Ex d[ia] IIC CSA 06.1674267
T6 (-50°C to 70°C)
Factory Sealed
Single Seal.
Enclosure Type 4X.
I6 Intrinsically safe for use in Class I, II, III Division 1, Groups A, B, C, D, E, F, G;
Non-incendive for Class I, Division 2, Groups A, B, C and D
T4 (-50°C to 70°C)
Single Seal.
Enclosure Type 4X.
K6 E6 and I6 Combination
Combination Certifications
KB E5, I5, E6, and I6 Combination
