Reference Manual
00809-0100-4004, Rev BA
August 2010
Rosemount 8800D
www.emersonprocess.com/rosemount
Section 4 Operation
Diagnostics/service . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . page 4-1
Advanced Functionality . . . . . . . . . . . . . . . . . . . . . . . . . . . page 4-4
Detailed Set-Up . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . page 4-4
This section contains information for advanced configuration parameters and
diagnostics.
The software configuration settings for the Rosemount 8800D can be accessed
through a HART-based communicator or through a control system. The
software functions for the Field Communicator are described in detail in this
section of the manual. It provides an overview and summary of communicator
functions. For more complete instructions, see the communicator manual.
Before operating the Rosemount 8800D in an actual installation, you should
review all of the factory set configuration data to ensure that they reflect the
current application.
DIAGNOSTICS/SERVICE Use the following functions to verify that the flowmeter is functioning properly,
or when you suspect component failure or a problem with loop performance,
or when instructed to do so as part of a troubleshooting procedure. Initiate
each test with the Field Communicator or other HART-based communications
device.
Test/Status Under Test/Status choose from View Status or Self Test.
View Status
Allows you to view any error messages that may have occurred.
Configuration Status
Configuration status allows you to check the validity of the transmitter
configuration.
Density Test Calc
Allows for the test of the density calculation for saturated steam. The vortex
meter will calculate the associated steam density at a user entered
temperature value. Process Fluid must be set to Tcomp Sat Steam in order to
run this test.
Field Comm. 1, 2
Field Comm. 1, 2, 1
Field Comm. 1, 2, 1, 1
Field Comm. 1, 2, 1, 2
Field Comm. 1, 2, 1, 3
