Reference Manual
00809-0100-4004, Rev BA
August 2010
Rosemount 8800D
5-20
Attach the Meter Adapter
1. If you are using a conduit adapter or cable gland, slide it over the
plain end of the coaxial cable (the end without a ground wire).
2. Slide the meter adapter over the coaxial cable end.
3. Use a
5
/16-in. (8 mm) open end wrench to securely tighten the sensor
cable nut onto one end of the union.
4. Place the union onto the two screws extending out of the meter
adapter and tighten the two screws.
Connect the Coaxial Cable at the Meter Body
1. Pull the sensor cable out of the support tube slightly and securely
tighten the sensor cable nut onto the union.
NOTE
Do not stretch the sensor cable over 1.5-in. (40 mm) beyond the top of the
support tube. Damage to the sensor may occur if the sensor cable is stressed.
2. Place the meter adapter into the top of the support tube and line up
the screw holes.
3. Use a hex wrench to turn the three adapter screws counterclockwise
(outward) to engage the support tube.
4. Replace the access cover on the support tube (6-8-in. wafer style
only).
5. Tighten the conduit adapter or cable gland into the
meter adapter.
Coaxial Cable at the
Electronics Housing
Remove the Coaxial Cable from the Electronics Housing
1. Loosen the two housing screws from the housing adapter.
2. Remove the housing adapter from the housing.
3. Loosen and remove the coaxial cable nut from the base of the
electronics housing.
4. Remove the coaxial cable ground connection from the housing base
by loosening the housing base screw that is connecting it to the
housing base.
