Reference Manual
00809-0100-4004, Rev BA
August 2010
Rosemount 8800D
www.emersonprocess.com/rosemount
Appendix A Reference Data
Specifications . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . page A-1
Functional Specifications . . . . . . . . . . . . . . . . . . . . . . . . . page A-1
Performance Specifications . . . . . . . . . . . . . . . . . . . . . . . page A-15
Physical Specifications . . . . . . . . . . . . . . . . . . . . . . . . . . . page A-17
Dimensional Drawings . . . . . . . . . . . . . . . . . . . . . . . . . . . . page A-20
Ordering Information . . . . . . . . . . . . . . . . . . . . . . . . . . . . . page A-34
SPECIFICATIONS The following specifications are for the Rosemount 8800D, Rosemount 8800DR, and Rosemount
8800DD, except where noted. Information is included in this section for both HART and
F
OUNDATION
™
fieldbus transmitters.
FUNCTIONAL SPECIFICATIONS
Process Fluids
Liquid, gas, and steam applications. Fluids must be homogeneous and single-phase.
Line Sizes
Wafer
1
/2, 1, 1
1
/2, 2, 3, 4, 6, and 8 inches
(DN 15, 25, 40, 50, 80, 100, 150, and 200)
Flanged and Dual-Sensor Style
1
/2, 1, 1
1
/2, 2, 3, 4, 6, 8, 10, and 12 inches
(DN 15, 25, 40, 50, 80, 100, 150, 200, 250, and 300)
Reducer
1, 1
1
/2, 2, 3, 4, 6, 8, 10, and 12 inches
(DN 25, 40, 50, 80, 100, 150, 200, 250, and 300)
Pipe Schedules
Process piping Schedules 10, 40, 80, and 160.
NOTE
The appropriate bore diameter of the process piping must be entered using
the Field Communicator or AMS Device Manager. Meters will be shipped from
the factory at the Schedule 40 default value unless otherwise specified.
Measurable Flow Rates
Capable of processing signals from flow applications which meet the sizing requirements below.
To determine the appropriate flowmeter size for an application, process conditions must be within
the Reynolds number and velocity limitations for the desired line size provided in Table A-1,
Table A-2, and Table A-3.
