Reference Manual
00809-0100-4004, Rev BA
August 2010
5-23
Rosemount 8800D
NOTE:
This will expose the electronics to the atmosphere.
5. Insert new temperature sensor into electronics housing using care to
align pin and cap head screw to align connector pins.
6. Tightening cap head screw with 2.5 mm allen wrench.
7. Slide bolt and ferrule assembly onto temperature sensor and hold into
place.
8. Insert temperature sensor into hole in bottom of meter body until it
reaches the bottom of the hole. Hold it in place and tighten bolt with
1
/2-in. open end wrench until
3
/4 turns past finger tight to seat ferrule.
9. Reapply power to Rosemount 8800D.
RETURN OF MATERIAL To expedite the return process, call the Rosemount North American
Response Center at 800-654-RSMT (7768) toll-free number.
This center, available 24 hours a day, will assist you with any needed
information or materials.
The center will ask for product model and serial numbers, and will provide a
Return Material Authorization (RMA) number. The center will also ask for the
name of the process material to which the product was last exposed.
CAUTION
People who handle products exposed to a hazardous substance can avoid
injury if they are informed and understand the hazard. If the product being
returned was exposed to a hazardous substance as defined by OSHA, a copy
of the required Material Safety Data Sheet (MSDS) for each hazardous
substance identified must be included with the returned goods.
The Rosemount North American Response Center will detail the additional
information and procedures necessary to return goods exposed to hazardous
substances.
