Rosemount 8800D Series User Manual

Reference Manual
00809-0100-4004, Rev BA
August 2010
Rosemount 8800D
A-34
ORDERING INFORMATION
Table A-29. Rosemount 8800D Vortex Flowmeter Ordering Information
★ The Standard offering represents the most common options. The starred options (★) should be selected for best delivery.
__The Expanded offering is subject to additional delivery lead time.
Model Product Description
8800D Vortex Flowmeter
Meter Style
Standard Standard
F Flanged style ★
W Wafer style ★
R Reducer Style (Flanged style only) ★
Expanded
D Dual-sensor style (Flanged style only)
Line Size
Standard Standard
005
1
/2-in. (15 mm) (Not available for Rosemount 8800DR) ★
010 1-in. (25 mm) ★
015 1
1
/2-in. (40 mm) ★
020 2-in. (50 mm) ★
030 3-in. (80 mm) ★
040 4-in. (100 mm) ★
Expanded
060 6-in. (150 mm)
080 8-in. (200 mm)
100 10-in. (250mm)
120 12-in. (300mm)
Wetted Materials
Standard Standard
S 316 wrought stainless and CF-3M cast stainless
Note: Material of construction is 316/316L
★
Expanded
H UNS N06022 wrought Nickel Alloy; CW2M cast Nickel Alloy
Note: See Table A-30 on page A-38
Other wetted materials are available. Consult factory for details.
Flange or Alignment Ring Size
Standard Standard
A1 ASME B16.5 (ANSI) RF Class 150 ★
A3 ASME B16.5 (ANSI) RF Class 300 ★
D1 DIN PN 16 (PN 10/16 for wafer-style) 2526-Type D ★
D3 DIN PN 40 (PN 25/40 for wafer-style) 2526-Type D ★
Expanded
A6 ASME B16.5 (ANSI) RF Class 600
A7
(1)
ASME B16.5 (ANSI) RF Class 900
A8
(2)
ASME B16.5 (ANSI) RF Class 1500
B1 ASME B16.5 (ANSI) RTJ Class 150 for flange-style only
B3 ASME B16.5 (ANSI) RTJ Class 300 for flange-style only
B6 ASME B16.5 (ANSI) RTJ Class 600 for flange-style only
B7
(1)
ASME B16.5 (ANSI) RTJ Class 900 for flange-style only
B8
(2)
ASME B16.5 (ANSI) RTJ Class 1500 for flange-style only
C1 ASME B16.5 (ANSI) RF Class 150, smooth finish
C3 ASME B16.5 (ANSI) RF Class 300, smooth finish
C6 ASME B16.5 (ANSI) RF Class 600, smooth finish
C7
(1)
ASME B16.5 (ANSI) RF Class 900, smooth finish
C8 ASME B16.5 (ANSI) RF Class 1500, smooth finish

Rosemount 8800D Series Specifications

General

Type	Vortex Flow Meter
Measurement Principle	Vortex Shedding
Operating Temperature	-40 to 185°F (-40 to 85°C)
Storage Temperature	-40 to 185°F (-40 to 85°C)
Communication Protocols	FOUNDATION Fieldbus
Material	316 stainless steel
Fluid Type	Liquid, Gas, Steam
Line Size	1/2 to 8 inches (15 to 200 mm)
Approvals	ATEX, IECEx, CSA, FM
Output Signal	4-20 mA
Process Connection	Flanged, Wafer, Threaded
Electrical Connection	M20
Protection Rating	IP66
Mounting Style	Wafer, Flanged
