Rosemount 8800D Series User Manual

Reference Manual
00809-0100-4004, Rev BA
August 2010
Rosemount 8800D
A-38
Table A-30. Method of Construction for the 8800DF in Nickel Alloy
Line Size A1 A3 A6 A7 D1 D3 D4 D6 D7
½ (15) C C C W W W NA W W
1 (25) C C C W W W NA W W
1½ (40) C C C W W W NA W W
2 (50) C C C W C C W W W
3 (80) C C C W C C W W W
4 (100) C C C W C C W W W
6 (150) C C C CF W W W W CF
8 (200) C C C CF W W W W CF
10 (250) W W W NA W W W W NA
12 (300) W W W NA W W W W NA
C = Nickel Alloy collar and 316 SST lap flange. If weld neck flange is required, V0022 can be ordered.
W = Nickel Alloy weld neck flange.
CF = Consult Factory
NA = Not Available
All 8800DR Reducer Vortex Meters with Nickel Alloy C materials of construction use weld neck flanges.

Rosemount 8800D Series Specifications

General

Type	Vortex Flow Meter
Measurement Principle	Vortex Shedding
Operating Temperature	-40 to 185°F (-40 to 85°C)
Storage Temperature	-40 to 185°F (-40 to 85°C)
Communication Protocols	FOUNDATION Fieldbus
Material	316 stainless steel
Fluid Type	Liquid, Gas, Steam
Line Size	1/2 to 8 inches (15 to 200 mm)
Approvals	ATEX, IECEx, CSA, FM
Output Signal	4-20 mA
Process Connection	Flanged, Wafer, Threaded
Electrical Connection	M20
Protection Rating	IP66
Mounting Style	Wafer, Flanged
