Rosemount 8800D Series User Manual

Reference Manual
00809-0100-4004, Rev BA
August 2010
A-37
Rosemount 8800D
R20 Remote electronics with 20 ft (6,1 m) cable ★
R30 Remote electronics with 30 ft (9,1 m) cable ★
R33 Remote electronics with 33 ft. (10 m) cable ★
R50 Remote electronics with 50 ft (15,2 m) cable ★
Expanded
RXX
(11)
Remote electronics with customer-specified cable length (up to 75 ft (23 m) maximum)
CPA
(12)
CriticalProcess Online Sensor
Certification Options
Standard Standard
Q4 Calibration data sheet per ISO 10474 3.1B and EN 10204 3.1 ★
Q8 Material traceability certification per ISO 10474 3.1B and EN 10204 3.1 ★
QP Calibration certification and tamper evident seal ★
Q25 NACE MR0103 Certificate of Compliance ★
Q66 Certificate for Procedure Qualification Records (PQR) ★
Q67 Certificate for Welder Performance Qualification (WPQ) Records ★
Q68 Certification for Welding Procedure Specifications (WPS) ★
Q69
(13)
Inspection certificate weld examination (wafer) per ISO 10474 3.1B and EN 10204 3.1
★
Q70 Inspection certificate weld examination (flanged) per ISO 10474 3.1B and EN 10204 3.1 ★
Q71 Inspection certificate weld examination (flanged) per ISO 10474 3.1B (includes x-rays) and EN 10204 3.1 ★
Q79 Certification for Combo PQR/WPQ/WPS ★
Expanded
QKH KHK Documentation Package
Quick Installation Guide (QIG) Language Options (Default is English)
Standard Standard
YA Danish QIG ★
YB Hungarian QIG ★
YC Czech QIG ★
YD Dutch QIG ★
YF French QIG ★
YG German QIG ★
YH Finnish QIG ★
YI Italian QIG ★
YJ Japanese QIG ★
YM Chinese (Mandarin) QIG ★
YN Norwegian QIG ★
YL Polish QIG ★
YP Portuguese QIG ★
YR Russian QIG ★
YS Spanish QIG ★
YW Swedish QIG ★
Typical Model Number: 8800D F 020 S A1 N 1 D 1 M5
(1) Available on flanged and dual style meters from
1
/2” - 8” (15-200 mm) and Reducer style meters from 1” - 6” (25-150 mm).
(2) Only available for stainless steel flange and dual style meters from 1” - 8” (25-200 mm). Consult factory for other materials.
(3) W1, W4, W8, and W9 are only available with Meter Style F from
1
/2-in. (15 mm) to 4-in. (100 mm) in SST.
(4) No TIIS approval
(5) Available with Rosemount 8800DF from 1
1
/2-in (40 mm) through 12-in. (300 mm). Available with 8800DR from 2-in (50 mm) through 12-in (300 mm). Not
available with 8800DW or 8800DD.
(6) Fieldbus Intrinsic Safe Concept (FISCO) available with output code F (F
OUNDATION fieldbus digital signal) only.
(7) TIIS Flameproof Approval requires G
1
/2 conduit entry.
(8) Requires output code F.
(9) Not available with certain hazardous location certifications. Contact a Rosemount representative for details.
(10) NAMUR compliant operation and the alarm latch options are pre-set at the factory and can be changed to standard operation in the field.
(11) XX is a customer specified length in feet.
(12) The CPA option is not available on wafer,
1
/2-in. flange, or 1-in. reducer units. In addition it is not available on 1" flanged and 1.5" reducer JIS 10K, DIN
PN40, or DIN PN16.
(13) Q69 available for all Nickel Alloy wafers and stainless steel wafers in line sizes
1
/2-in. (15 mm), 6-in. (150 mm), and 8-in. (200 mm).
Table A-29. Rosemount 8800D Vortex Flowmeter Ordering Information
★ The Standard offering represents the most common options. The starred options (★) should be selected for best delivery.
__The Expanded offering is subject to additional delivery lead time.

Rosemount 8800D Series Specifications

General

Type	Vortex Flow Meter
Measurement Principle	Vortex Shedding
Operating Temperature	-40 to 185°F (-40 to 85°C)
Storage Temperature	-40 to 185°F (-40 to 85°C)
Communication Protocols	FOUNDATION Fieldbus
Material	316 stainless steel
Fluid Type	Liquid, Gas, Steam
Line Size	1/2 to 8 inches (15 to 200 mm)
Approvals	ATEX, IECEx, CSA, FM
Output Signal	4-20 mA
Process Connection	Flanged, Wafer, Threaded
Electrical Connection	M20
Protection Rating	IP66
Mounting Style	Wafer, Flanged
