Reference Manual
00809-0100-4004, Rev BA
August 2010
B-3
Rosemount 8800D
European Certifications
ATEX Intrinsic Safety
I1 Certification No. Baseefa05ATEX0084X
ATEX Marking II 1 G
EEx ia IIC T5 (-60°C
T
a
40°C)
EEx ia IIC T4 (-60°C
T
a
70°C)
Input Parameters:
U
i
= 30 Vdc
I
i
(1)
= 185 mA
P
i
(1)
= 1.0 W
C
i
= 0 F
L
i
= 0.97 mH
0575
SPECIAL CONDITIONS
When fitted with 90V transient suppressors (T1 Option), the equipment is not
capable of passing the 500V isolation test. This must be taken into account
upon installation.
ATEX Type N Certification
N1 Certification No. Baseefa05ATEX0085X
ATEX Marking II 3 G
EEx nAnL II T5 (-40°C
T
a
70°C)
Input Parameters:
U
i
= 42 V dc Max
C
i
= 0 F
L
i
= 0.97 mH
SPECIAL CONDITIONS
When fitted with 90V transient suppressors (T1 Option), the equipment is not
capable of passing the 500V isolation test. This must be taken into account
upon installation.
ATEX Flameproof Certification
E1 Certification No. KEMA99ATEX3852X
ATEX Marking Remote Mount:
Transmitter: II 2(1) G
EEx d [ia] IIC T6 (-50°C T
a
70°C)
Meter Body: II 1 G
EEx ia IIC T6 (-50°C T
a
70°C)
ATEX Marking Integral Mount: II 1/2 G
EEx d [ia] IIC T6 (-50°C T
a
70°C)
0575
V = 42 Vdc Max
Um = 250V
SPECIAL CONDITIONS
When the equipment is installed, precautions must be taken to ensure, taking
into account the effect of the fluid temperature, that the ambient temperature
of the electrical parts of the equipment is comprised between -50°C and 70°C.
The remote mounted sensor may only be connected to the transmitter with
the associated cable, supplied by the manufacturer.
ATEX Dust Certification
ND Certification No. Baseefa05ATEX0086/3
II 1D Ex tD A20 IP66 T90°C (-20°C
Ta
70°C)
42 VDC Max
K1 E1, I1, N1 and ND Combination
(1) Total for transmitter
