Reference Manual
00809-0100-4004, Rev BA
August 2010
2-9
Rosemount 8800D
Wafer-Style Flowmeter
Alignment and Mounting
Center the wafer-style meter body inside diameter with respect to the inside
diameter of the adjoining upstream and downstream piping. This will ensure
that the flowmeter achieves its specified accuracy.
Alignment rings are provided with each wafer-style meter body for centering
purposes. Follow these steps to align the meter body for installation. Refer to
Figure 2-7 on page 2-11.
Table 2-3. Minimum Recommended Stud Bolt Lengths for Wafer Installation
with ASME B16.5 (ANSI) Flanges
Minimum Recommended Stud Bolt Lengths
(in Inches) for Each Flange Rating
Line Size Class 150 Class 300 Class 600
½-inch 6.00 6.25 6.25
1-inch 6.25 7.00 7.50
1½-inch 7.25 8.50 9.00
2-inch 8.50 8.75 9.50
3-inch 9.00 10.00 10.50
4-inch 9.50 10.75 12.25
6-inch 10.75 11.50 14.00
8-inch 12.75 14.50 16.75
Table 2-4. Minimum Recommended Stud Bolt Lengths for
Wafer Installation with DIN Flanges
Minimum Recommended Stud Bolt Lengths
(in mm) for Each Flange Rating
Line Size PN 16 PN 40 PN 64 PN 100
DN 15 160 160 170 170
DN 25 160 160 200 200
DN 40 200 200 230 230
DN 50 220 220 250 270
DN 80 230 230 260 280
DN 100 240 260 290 310
DN 150 270 300 330 350
DN 200 320 360 400 420
Table 2-5. Minimum Recommended Stud Bolt Lengths for
Wafer Installation with JIS Flanges
Minimum Recommended Stud Bolt Lengths
(in mm) for Each Flange Rating
Line Size JIS 10k JIS 16k and 20k JIS 40k
15mm 150 155 185
25mm 175 175 190
40mm 195 195 225
50mm 210 215 230
80mm 220 245 265
100mm 235 260 295
150mm 270 290 355
200mm 310 335 410
