Rosemount 8800D Series User Manual

Reference Manual
00809-0100-4004, Rev BA
August 2010
A-35
Rosemount 8800D
D0 DIN PN 10 2526-Type D
D2 DIN PN 25 2526-Type D
D4 DIN PN 64 2526-Type D
D6 DIN PN 100 2526-Type D
D7
(1)
DIN PN 160 2526-Type D
D8 DIN PN 250 2526-Type D
G0 DIN PN 10 2512-Type N for flange-style only
G1 DIN PN 16 2512-Type N for flange-style only
G2 DIN PN 25 2512-Type N for flange-style only
G3 DIN PN 40 2512-Type N for flange-style only
G4 DIN PN 64 2512-Type N for flange-style only
G6 DIN PN 100 2512-Type N for flange-style only
G7
(1)
DIN PN 160 2512-Type N for flange-style only
G8 DIN PN 250 2512-Type N for flange-style only
H0 DIN PN 10 2526-Type E
H1 DIN PN 16 (PN 10/16 for wafer-style) 2526-Type E
H2 DIN PN 25 2526-Type E
H3 DIN PN 40 (PN 25/40 for wafer-style) 2526-Type E
H4 DIN PN 64 2526-Type E
H6 DIN PN 100 2526-Type E
H7
(1)
DIN PN 160 2526-Type E
H8 DIN PN 250 2526-Type E
J1 JIS 10K
J2 JIS 20K
J4 JIS 40K
W1
(3)
Weld End, Schedule 10S
W4
(3)
Weld End, Schedule 40S
W8
(3)
Weld End, Schedule 80S
W9
(3)
Weld End, Schedule 160S
Sensor Process Temperature Range
Standard Standard
N Standard: -40 to 450°F (-40 to 232°C) ★
E Extended: -330 to 800°F (-200 to 427°C) ★
Conduit Entry
Standard Standard
1
1
/2 -14 NPT – Aluminum Housing ★
2 M20  1.5 – Aluminum Housing ★
4 G
1
/2 (One Conduit Entry) – Aluminum Housing ★
5 G
1
/2 (Two Conduit Entries) – Aluminum Housing ★
Expanded
6
(4) 1
/2 - 14 NPT - SST Housing
7
(4)
M20 x 1.5 - SST Housing
Outputs
Standard Standard
D 4-20 mA digital electronics (HART protocol) ★
P 4-20 mA digital electronics (HART protocol) with scaled pulse ★
F FOUNDATION fieldbus digital signal
★
Calibration
Standard Standard
1 Flow calibration ★
Table A-29. Rosemount 8800D Vortex Flowmeter Ordering Information
★ The Standard offering represents the most common options. The starred options (★) should be selected for best delivery.
__The Expanded offering is subject to additional delivery lead time.

Rosemount 8800D Series Specifications

General

Type	Vortex Flow Meter
Measurement Principle	Vortex Shedding
Operating Temperature	-40 to 185°F (-40 to 85°C)
Storage Temperature	-40 to 185°F (-40 to 85°C)
Communication Protocols	FOUNDATION Fieldbus
Material	316 stainless steel
Fluid Type	Liquid, Gas, Steam
Line Size	1/2 to 8 inches (15 to 200 mm)
Approvals	ATEX, IECEx, CSA, FM
Output Signal	4-20 mA
Process Connection	Flanged, Wafer, Threaded
Electrical Connection	M20
Protection Rating	IP66
Mounting Style	Wafer, Flanged
