Wireless Router RNX-N150RT User Manual
1.2 Main Features
 Make use of IEEE 802.11nwireless technology to provide a wireless data rate of up to
150Mbps.
 One 10/100M Auto-Negotiation RJ45 WAN port, four 10/100MAuto-NegotiationRJ45 LAN
ports, supporting Auto MDI/MDIX.
 Provides WPA/WPA2, WPA-PSK/WPA2-PSK authentication, TKIP/AES encryption security.
 Shares data and Internet access for users, supporting Dynamic IP/Static IP/PPPoE Internet
access.
 Supports Virtual Server, Special Application and DMZ host.
 Supports UPnP, Dynamic DNS, Static Routing.
 Provides Automatic-connection and Scheduled Connection on certain time to the Internet.
 Connects Internet on demand and disconnects from the Internet when idle for PPPoE.
 Built-in NAT and DHCP server supporting static IP address distributing.
 Supports Stateful Packet Inspection.
 Supports VPN Passthrough.
 Supports Parental Control and Access Control.
 Provides 64/128/152-bit WEP encryption security and wireless LAN ACL (Access Control
List).
 Supports Flow Statistics.
 Supports firmware upgrade and Web management.
1.3 Panel Layout
1.3.1 The Front Panel
Figure 1-1 Front Panel sketch
The router’s LEDs and the WPS/Reset Button are located on the front panel (View from left to
right).
Name Status Indication
Off
Power is off.
PWR
On Power is on.
- 3 -
