ROTAX 125 MAX evo, Junior MAX evo, Mini MAX evo, Micro MAX evo
11. Installation of the exhaust system
General:
Note: On the underside of the exhaust system, two different mounting mechanisms are
provided. At the front, the assembly is carried out with rubber buffer (pos. 7)
between the retaining plate (pos. 6) and the exhaust system and attached by
extension springs (pos. 8). At the rear, the exhaust system is mounted directly using
rubber mounts M8 (pos. 9).
Attention: A rigid suspension of the exhaust system could result in fractures in the exhaust
system.
Attach the high temperature resistant rubber mounts (pos. 9) on the two support
lugs on the underside of the tuned exhaust.
Arrange the chassis-specific supports so that the exhaust system follows the
straightest possible course from the exhaust socket on the cylinder to the muffler.
The gasket (Pos. 13) is the only sealing between engine and the exhaust system.
The special material eliminates the brushing of the sealing surfaces.
Note: All engine types have the same gaskets!
Note: A leakage in the exhaust system may lead to performance loss.
Secure the exhaust system on ball joint, using two supplied exhaust springs (pos.
14).
Note: For easier installation use the special tool "spring hook" part no. 251680.
Attention: Do not over-stress the springs when fitting them.
Attach the exhaust system on the chassis supports, such that the sealing of the ball
joint between cylinder and exhaust system will not be impaired.
Configuration 125 Micro MAX evo:
The exhaust system (pos. 14) is provided only for the engine type 125 Micro MAX evo. Also the
exhaust socket part no. 273192 (Pos. 13) was developed only for the configuration 125 Micro MAX
evo.
Engine type Exhaust socket part no. Exhaust socket ø
125 Micro MAX evo 273192 Ø 18 mm / 0.71 in.
Configurations 125 MAX evo Junior MAX evo, Mini MAX evo:
The exhaust system part no. 273178 (pos. 2) is provided for the engine types 125 MAX evo, Junior
MAX evo und Mini MAX evo. Only the exhaust sockets are different:
Engine type Exhaust socket part no. Exhaust socket ø
125 MAX evo 273190 Ø 37 mm / 1.46 in.
125 Junior MAX evo 273190 Ø 37 mm / 1.46 in.
125 Mini MAX evo 273194 Ø 20 mm / 0.79 in.
Seite/page 67/98
Ausgabe/Edition 11/2014
