Rotax 912 i series Service Manual

BRP-Rotax
MAINTENANCE MANUAL LINE
Engine test run Engine test run is necessary:
Step
Procedure
1
Operate the engine until the temperatures have stabilized for a period of 5
min. (engine oil temperature between 50 to 70 °C (122 - 160 °F).
2
Switch the engine OFF.
3 Allow the engine to cool down.
4
Check for leaks.
5
Check the coolant level and top up with coolant as required.
12–10–00
Page 6
September 01/2018
Effectivity: 912 i Series
Edition 2/Rev. 0

Rotax 912 i series Specifications

General

Number of Cylinders	4
Max Power	100 hp (73.5 kW)
Max Power Output RPM	5800 rpm
Ignition System	Dual electronic ignition
Oil System	Dry sump, forced lubrication with separate oil tank
Reduction Gear Ratio	2.43:1
TBO	2000 hours
Engine Type	4-stroke, horizontally opposed
Displacement	1352 cm³
Bore x Stroke	84 mm x 61 mm
Max Torque	128 Nm
Fuel Type	Avgas 100LL or unleaded automotive gasoline
Fuel System	Electronic fuel injection
Cooling System	Liquid/air-cooled
