MAINTENANCE MANUAL LINE
ATTENTION
For longer flights replenish oil to max. mark to warrant more oil reserve.
ATTENTION
Only use brand name oil in accordance with the latest Operators Manual and the
latest Service Instruction “Selection of suitable operating fluids“ of the respec-
tive engine type.
Step
Procedure
6 Replenish oil as required.
7
Check oil level - Marks on the oil dipstick.
8 Fit the oil dipstick and tighten the oil tank cover (1) by hand.
Figure 6.4: Oil level check/Replenish
1 Oil tank cover 2
Oil dipstick
12–10–00
Page 8
September 01/2018
Effectivity: 912 i Series
Edition 2/Rev. 0

Rotax 912 i series Specifications

General

Number of Cylinders	4
Max Power	100 hp (73.5 kW)
Max Power Output RPM	5800 rpm
Ignition System	Dual electronic ignition
Oil System	Dry sump, forced lubrication with separate oil tank
Reduction Gear Ratio	2.43:1
TBO	2000 hours
Engine Type	4-stroke, horizontally opposed
Displacement	1352 cm³
Bore x Stroke	84 mm x 61 mm
Max Torque	128 Nm
Fuel Type	Avgas 100LL or unleaded automotive gasoline
Fuel System	Electronic fuel injection
Cooling System	Liquid/air-cooled
