Rotax 912 i series Service Manual

BRP-Rotax
MAINTENANCE MANUAL LINE
No.
part no. Description, Application Qty.
For vibration damping
(0.082 gal (US))
V 297386 Locking paint
AG
897186
SILICONE HEAT CONDUCTION
COMPOUND,
Application of the heat conduction compound
will increase heat transfer resistance. The
greaselike, temperature-resistant silicon com-
pound fills cavities between components and
the cooling element (e.g.: spark plug-cylinder
head), which otherwise do not contribute to heat
conduction.
150 g
(0.33 lb)
Z 899789 LOCTITE 603
Oil tolerant retainer retaining compound, heavy-
duty
10 ml (0.003 gal
(US))
Figure 2.1: Consumable materials
05–00–00
Page 8
September 01/2018
Effectivity: 912 i Series
Edition 2/Rev. 0

Rotax 912 i series Specifications

General

Number of Cylinders	4
Max Power	100 hp (73.5 kW)
Max Power Output RPM	5800 rpm
Ignition System	Dual electronic ignition
Oil System	Dry sump, forced lubrication with separate oil tank
Reduction Gear Ratio	2.43:1
TBO	2000 hours
Engine Type	4-stroke, horizontally opposed
Displacement	1352 cm³
Bore x Stroke	84 mm x 61 mm
Max Torque	128 Nm
Fuel Type	Avgas 100LL or unleaded automotive gasoline
Fuel System	Electronic fuel injection
Cooling System	Liquid/air-cooled
