MAINTENANCE MANUAL LINE
F
10202
specially prepared lever
propeller ange
support of specially
prepared lever
torque wrench
Figure 5.10: Front view
10201
specially pre-
pared lever
propeller ange
support of specially
prepared lever
torque wrench
adapter plate
Figure 5.11: Side view
Effectivity: 912 i Series
Edition 2/Rev. 0
05–50–00
Page 13
September 01/2018
