EbV Product documentation THETA NORM/UNIT
5-12
5.1.2.7.1 Temperature displays
The following information appear only under the indicated display conditions. Some displays are not
available and are skipped according to the respective type of control.
INFORMATION Displayed value Remarks Application
Outdoor temp. (1) Average value /
current value
Outside sensor connected
Outdoor temp. (1) Min-max-value
(0.00 to 24.00 Uhr)
Outside sensor connected
Outdoor temp. 2 Average value /
current value
Outdoor sensor 2 at variable input
Outdoor temp. 2 Min-max-value
(0.00 to 24.00 Uhr)
Outdoor sensor 2 at variable input
Heat generator (1) Nominal/actual value Only if heat generator is defined (..2..)
Heat generator 2 Nominal/actual value Sensor BS 2 at variable input (..2..)
Return flow (b. contr.) Actual value Return flow sensor connected at
boiler control
(..C..)
Flue gas (b. contr.) Actual value Flue gas sensor connceted at
boiler control
(..C..)
Return flow Nominal/actual value Return flow sensor at var. input and
return temp. increasing activated
External blocking Block mode
ON/OFF
Ext. blocking at variable input
Flue gas Limit value/
Actual value
Flue gas sensor at variable input (..2..)
Hot water tank (1) Nominal/actual value Only with hot water tank (..B..)
Hot water tank 2 Nominal/actual value Hot water sensor 2 at var. input (..B..)
Hot water thermostat Charging status
ON/OFF
Instead of an electronic sensor (..B..)
Demand via contact
(VI1)
Demand
ON/OFF
Switching contact at variable input
Demand via contact
(VI2)
Demand
ON/OFF
Switching contact at variable input
Demand via contact
(VI3)
Demand
ON/OFF
Switching contact at variable input
Flow
Mixing circuit 1
Nominal/actual value Flow sensor mix. heating circuit 1
connected
(..3..)
Flow
Mixing circuit 2
Nominal/actual value Flow sensor mix. heating circuit 1
connected
(..33..)
Ambient temper.
Unmixed heating circuit
Nominal/actual value Remote control necessary (..2..)
Ambient temper.
Mixing circuit 1
Nominal/actual value Remote control necessary (..3..)
