48  April 2015  IMO_374_EN_v1 Roto Patio Fold Subject to change.
Installation
Sash
Mounting support bracket for bottom enhanced threshold
26+X
5
18.5
15.5
6
19.5
17
22
19
20.5
13
10
9.5
30.5
30
14.5
5
5
5
6
6
14.7
13
26+X
5
30.5
27.5
6
31.5
29
34
31
32.5
5
5
5
6
6
13
10
9.5
30.5
30
14.5
26.7
13
NOTE!
 Observe the profile-specific installation
instructions , because aluminium profile
systems must be drilled in timber or PVC
position (pay attention to the profile
assessment ).
 Seal the holes for the outer support brackets
with suitable sealing compound to prevent
the ingress of water.
 Explanation of dimension “X”, page47.
 Shorten the additional screw for aluminium
profile with Euro-groove if necessary, if
hardware is used in this area.
NOTE!
Shorten the additional screw for the Euro-groove
if necessary, if hardware is used in this area.
