Installation
Frame
Installing contour-milled frame
6.
Secure the threshold bracket.
NOTE!
The screws shown are in the misc. small
components pack of the enhanced threshold.
8.
7.
8.
Recommendation: Self-tapping screws (choice on site)
ISO7050 – ST4.2x... – C – Z, stainless steel A2
Seal the gap between the threshold bracket and
cover cap with a suitable sealing compound to
prevent
the ingress of water.
9.
Fix the threshold bracket with self-tapping screws
4.2x25.
NOTE!
The screws shown are in the misc. small
components pack of the enhanced threshold.
NOTE!
When ordering profile-specific threshold
brackets, pay attention to the screw
positions
(see red identifier) to the corner
connector of the enhanced threshold.
