Installation
Frame
Installing contour-milled frame
10.
Cut the profile stabiliser (e.g. made of solid PVC) to
match the frame profile.
11.
Insert profile stabiliser and screw it securely to the
enhanced threshold.
NOTE!
Coordinate the length of the screws to the
on-site conditions.
12.
Secure the frame.
Recommendation: Self-tapping screws (choice on site)
ISO7050–ST4.2x... – C – Z, stainless steel A2
NOTE!
Coordinate the length of the screws to the
on-site conditions.
Generally, screw into the reinforcement.
NOTE!
Seal the holes for the outer fastenings with
suitable sealing compound to prevent the
ingress of water.
