Section 6 Maintenance H85A Manual
www.rottlermfg.com
6-1
Maintenance
Follow all relevant safety procedures as described in Section 3 of this manual before
performing any maintenance or repair procedure.
Lubrication
Refer to the Material Safety Data Sheets on the manual CD for information on
proper use and handling of lubricants mentioned in this maintenance section.
Grease Fittings
There are grease ttings on the main carriage assembly, the optional clamp arm assemblies, and the
optional Turn Over Fixture. See the following images for locations of grease ttings and intervals for adding
grease.
These grease ttings should be greased, using NLGI #2 White Lithium Grease.
Automatic Lubricator
The oil injection lubricator is located on the back of the main base. The oil injector lubricates the ballscrews.
The automatic injection lubricator is controlled by the machine program. The controller will activate the
injection lubricator at a predetermined time interval
When needed, add lubrication oil to the reservoir. Use ISO VG 68 Way Oil.
Electrical Enclosure
On a weekly basis check the door air lter and the aluminum nned heat sink and fan assembly. Replace
the air lter when if becomes dirty. Blow off the heat sink and fan when it becomes covered in dust. Refer to
the Machine Parts section of this manual for more details and for part number of the lter.
