Section 2 Installation H85A Manual
www.rottlermfg.com
2-11
Work Envelope Dimensions
Side View
Side View
20.17 - 14.52
[512.2 - 368.7]
MANUAL Y-TRAVEL
19.92 - 14.77
[505.9 - 375.1]
AUTOMATIC Y-TRAVEL
