Rottler H85A - Stone Holder Size Charts H85 A

Section 4 Control Denitions H85A Manual
www.rottlermfg.com
4-15
STONE HOLDER SIZE CHARTS H85A
MEDIUM HONE HEAD
Diameter (New Stones)
0.312 Stones 0.200 Stones
Min Max Min Max
514-10-13A 2.34 2.45 2.12 2.23
514-10-13F 2.44 2.55 2.22 2.33
514-10-13B 2.54 2.65 2.32 2.43
514-10-13G 2.64 2.75 2.42 2.53
514-10-13C 2.74 2.85 2.52 2.63
514-10-13H 2.84 2.95 2.62 2.73
514-10-13D 2.94 3.05 2.72 2.83
Diameter (New Stones) (Metric)
7.925 Stones 5.08 Stones
Min Max Min Max
514-10-13A 59.44 62.23 53.75 56.54
514-10-13F 61.98 64.77 56.29 59.08
514-10-13B 64.52 67.31 58.83 61.62
514-10-13G 67.06 69.85 61.37 64.16
514-10-13C 69.60 72.39 63.91 66.70
514-10-13H 72.14 74.93 66.45 69.24
514-10-13D 74.68 77.47 68.99 71.78
Diameter (New Brushes )
0.550 Brushes 0.395 Brushes
Min Max Min Max
514-10-13A 2.82 2.93 2.51 2.62
514-10-13F 2.92 3.03 2.61 2.72
514-10-13B 3.02 3.13 2.71 2.82
514-10-13G 3.12 3.23 2.81 2.92
514-10-13C 3.22 3.33 2.91 3.02
514-10-13H 3.32 3.43 3.01 3.12
514-10-13D 3.42 3.53 3.11 3.22
Diameter (New Brushes) (Metric)
13.970 Brushes 10.033 Brushes
Min Max Min Max
514-10-13A 71.53 74.32 63.65 66.45
514-10-13F 74.07 76.86 66.19 68.99
514-10-13B 76.61 79.40 68.73 71.53
514-10-13G 79.15 81.94 71.27 74.07
514-10-13C 81.69 84.48 73.81 76.61
514-10-13H 84.23 87.02 76.35 79.15
514-10-13D 86.77 89.56 78.89 81.69
