LARGE HONE HEAD
Diameter (New Stones)
0.312 Stones 0.200 Stones
Min Max Min Max
514-9-6J 2.99 3.45 2.77 3.23
514-9-6A 3.17 3.63 2.94 3.41
514-9-6B 3.42 3.88 3.19 3.66
514-9-6C 3.67 4.13 3.44 3.91
514-9-6D 3.92 4.38 3.69 4.16
514-9-6E 4.17 4.63 3.94 4.41
514-9-6F 4.42 4.88 4.19 4.66
514-9-6G 4.67 5.13 4.44 4.91
514-9-6H 4.92 5.38 4.69 5.16
514-9-6K 5.17 5.63 4.94 5.41
514-9-6L 5.42 5.88 5.19 5.66
514-9-6M 5.67 6.13 5.44 5.91
514-9-6N 5.92 6.38 5.69 6.16
514-9-6P 6.17 6.63 5.94 6.41
514-9-6Q 6.42 6.88 6.19 6.66
514-9-6R 6.67 7.13 6.44 6.91
514-9-6S 6.92 7.38 6.69 7.16
Diameter (New Stones) (Metric)
7.925 Stones 5.08 Stones
Min Max Min Max
514-9-6J 75.92 87.73 70.23 82.04
514-9-6A 80.39 92.20 74.70 86.51
514-9-6B 86.74 98.55 81.05 92.86
514-9-6C 93.09 104.90 87.40 99.21
514-9-6D 99.44 111.25 93.75 105.56
514-9-6E 105.79 117.60 100.10 111.91
514-9-6F 112.14 123.95 106.45 118.26
514-9-6G 118.49 130.30 112.80 124.61
514-9-6H 124.84 136.65 119.15 130.96
514-9-6K 131.19 143.00 125.50 137.31
514-9-6L 137.54 149.35 131.85 143.66
514-9-6M 143.89 155.70 138.20 150.01
514-9-6N 150.24 162.05 144.55 156.36
514-9-6P 156.59 168.40 150.90 162.71
514-9-6Q 162.94 174.75 157.25 169.06
514-9-6R 169.29 181.10 163.60 175.41
514-9-6S 175.64 187.45 169.95 181.76
