EXTRA LARGE HONE HEAD
Diameter (New Stones)
0.312 Stones 0.200 Stones
Min Max Min Max
514-9-25A 6.11 6.43 5.89 6.21
514-9-25B 6.31 6.63 6.09 6.41
514-9-25C 6.61 6.93 6.39 6.71
514-9-25D 6.91 7.23 6.69 7.01
514-9-25E 7.21 7.53 6.99 7.31
514-9-25F 7.51 7.83 7.29 7.61
514-9-25G 7.81 8.13 7.59 7.91
514-9-25H 8.11 8.43 7.89 8.21
514-9-25J 8.41 8.73 8.19 8.51
514-9-25K 8.71 9.03 8.49 8.81
514-9-25L 9.01 9.33 8.79 9.11
514-9-25M 9.31 9.63 9.09 9.41
514-9-25N 10.89 11.21 10.67 10.99
514-9-25P 11.66 11.98 11.44 11.76
514-9-25Q 9.61 9.93 9.39 9.71
514-9-25R 9.91 10.23 9.69 10.01
514-9-25S 10.21 10.53 9.99 10.31
514-9-25T 10.51 10.83 10.29 10.61
514-9-25U 10.81 11.13 10.59 10.91
