Getting to Know the Access Point Features
ZoneFlex 7762-S Access Point
Ruckus Wireless Outdoor AP 100.1.0 User Guide, 800-70863-001 Rev A 27
7762-S 5GHz Antenna Connectors
If you want to enable the 5GHz sections of the AP (for access or meshing), you can
connect external high gain antennas (5GHz only) to the standard N-type radio
frequency (RF) antenna connectors on the top panel of the AP.
Figure 9. The 7762-S 5GHz antenna connectors are protected by metal caps
Make a note of the MAC
address on this label.
You will need it later.
Metal caps
