Navigating the Web Interface
You manage the AP through a Web browser-based interface that you can access
from any networked computer. Ta b le 2 3 lists the Web interface features that are
identified in Figure 26.
Figure 26. Elements of the Ruckus Wireless AP Web Interface
Table 23. Ruckus Wireless AP Web interface elements
No. Element Description
1 Menu Under each category (Status, Configuration, etc.) are options
that, when clicked, open the related workspace in the area to
the right.
2 Tabs Contains additional options for the configuration page. For
example, the
Configuration > Wireless page includes one tab
for common wireless configuration and eight tabs, one for each
of the available WLANs.
3 LOGOUT Button Click this button to log out of the AP.
4 Help Button Click this button to open a help window with information related
specifically to the options currently displayed in the workspace.
5 Workspace This large area displays features, options and indicators relevant
to your menu bar choices.
