Getting to Know the Access Point Features
ZoneFlex 7782-E Access Point
Ruckus Wireless Outdoor AP 100.1.0 User Guide, 800-70863-001 Rev A 45
2.4GHz
connectors:
ANT 0, ANT 1
and ANT 2
These 2.4GHz 50-ohm female connectors can be used with up to three external
antennas for operator-defined coverage areas and point-to-point deployments.
• When you are connecting two 2.4GHz antennas to the AP, use the ANT 0 and
ANT 2 2.4GHz connectors.
• When you are connecting three 2.4GHz antennas to the AP, use the all three
ANT 0, ANT 1 and ANT 2 2.4GHz connectors.
GPS connector This 50-ohm female N-type connector is used for a standard powered external
GPS antenna. The factory-supplied GPS antenna kit complies with all 7782-E
AP requirements.
If you are installing a customer-supplied antenna and extension cable, then keep
the cable short or use low-loss cable to avoid excess signal attenuation. The
7782-E supplies 3.3 VDC to the GPS antenna; make sure that a customer-
supplied GPS antenna does not require more than 150mA.
Table 15. 7782-E top-panel N-type connectors (Continued)
Label Description
