Getting to Know the Access Point Features
ZoneFlex T300e Outdoor Access Point
Ruckus Wireless Outdoor AP 100.1.0 User Guide, 800-70863-001 Rev A 57
Figure 23 identifies the 5GHz RF connectors on the AP. Ta b le 2 0 describes these
RF connectors.
If you want to extend the range of your wireless network, then you can connect
external high gain antennas to the standard N-type radio frequency (RF) antenna
connectors on the top panel of the AP. The antennas must have a gain of less than
9dBi to comply with FCC and CE regulations.
6
PWR
LED • Off: Off.
• Red: Boot up in process.
• Green: On.
7
PoE IN
RJ45 data
connector
Supports 10/100/1000Mbps connections, and receives Power
over Ethernet (PoE).
Note: The T300e can be powered by any 802.3af PSE device.
Refer to the Ruckus Wireless T300e data sheet for
recommended PoE accessories.
8
RESET
button
This button resets the AP to its factory defaults, and is mounted
under the
RESET/PoE IN RJ-45 waterproof gland.
Table 19. T300e LED and other element descriptions (Continued)
No. Label Description
