Getting to Know the Access Point Features
ZoneFlex T301s Outdoor Access Point
Ruckus Wireless Outdoor AP 100.1.0 User Guide, 800-70863-001 Rev A 64
6
PWR
LED • Off: Off.
• Red: Boot up in process.
• Green: On.
7
PoE IN
RJ45 data
connector
Supports 10/100/1000Mbps connections, and receives Power
over Ethernet (PoE).
Note: The T301s can be powered by any 802.3af PSE device.
Refer to the Ruckus Wireless T301s data sheet for
recommended PoE accessories.
8
RESET
button
This button resets the AP to its factory defaults, and is mounted
under the
RESET/PoE IN RJ-45 waterproof gland.
Table 22. T301s LED and other element descriptions (Continued)
No. Label Description
