6 Russound MCA-C3 User and Installation Manual
CONTROLLER FRONT PANEL
Removable cover to access IR
window and USB port
USB Port for Programming
IR Receiver Window
Zone LED indicators visible
behind cover
Power Switch
Red LED behind power indicator
Front Panel
Front Panel with cover removed
Red IR LED (talk-back)
