SYSTEM START-UP—ACCESSING PARAMETERS
22
• Pressing the enter (●) key saves the displayed
value. Press and hold the enter key until a check-
mark appears to the right of the value you wish to
enter. (Note: If the enter (●) key is not held down
long enough, the display will return to the previously
saved setting.) A checkmark next to the displayed
value indicates the currently saved value. An aster-
isk next to the displayed value indicates a value that
is not saved. (See Figure 30.)
• Pressing and releasing the enter (●) key jumps the
cursor back over to the three-digit parameter num-
ber.
NOTE: The RESET key also serves as the
ENTER key and the STOP key.
See Table 5 on page 30 for a complete list of
parameters available through the Operator Level.
Figure 29
Figure 30
Accessing Service Level 2
1. Access the Operator Level. (See “Navigating
Parameters” on page 21.)
2. To access Service Level 2, scroll to password
parameter 999 (P.999). Then briefly press and
release the reset (●) key. The cursor will jump from
the three-digit parameter number over to the param-
eter value on the display. (See Figure 31.)
Figure 31
3. Enter the password by first pressing the up (▲) or
down (▼) key until the numerical password required
for the desired service level is displayed.
(See Figure 32.)
Figure 32
4. Press the enter (●) key to accept the password and
enter that particular service level. A checkmark will
appear to the right of the value entered. Release the
enter key, then press and release the enter key (●)
once more. The cursor will jump back under the
three-digit parameter number and a large “S” will
appear on the display to indicate that Service Level
2 is accessed.
NOTE: The RESET key also serves as the
ENTER key and the STOP key.
5. Press the up (▲) or down (▼) key to scroll through
the list of available parameters for that particular
service level. (Only the parameters associated with
the accessed service level will be available.)
6. Access a displayed parameter by briefly pressing
the enter (●) key. The parameter is accessed when
the cursor jumps over to the currently saved value
for that parameter.
i
=
P:Posi t i on n
g
s
210 0 #
–
Cursor Position
9
when Scrolling
through Parameters
Cursor Position
Once Parameter
Is Accessed
Parameter
Number
i
=
P:Posi t i on n
g
s
210 5 #
–
9
Parameter
Value
Cursor
Operator Level (O)
Service Level 2 (S)
Parameter
Name or Group
Three-Digit
Parameter
Number
Unit
Parameter
Status
=
P:Password
999 #
–
000
Parameter
Value
Cursor
Operator Level (O)
Service Level 2 (S)
Parameter
Name or Group
Three-Digit
Parameter
Number
Unit
0
–
O
Parameter
Status
9
=
P:Password
999 #
Operator Level (O)
Service Level 2 (S)
Parameter
Name or Group
Three-Digit
Parameter
Number
Parameter
Status
Unit
0
Service Level 2)
Parameter Value
(Numerical Password
s
9
1
