RYTEC System 4 User Manual

MISCELLANEOUS MESSAGES—DOOR MESSAGES
48
MISCELLANEOUS MESSAGES
DOOR MESSAGES
Table 20 below lists the miscellaneous messages asso-
ciated with the control system. Included in this table are
the available displayed messages and a description and
definition of each message.
Table 20
SPECIAL STATUS MESSAGES
Table 21 below lists the special status messages asso-
ciated with the control system. Included in this table are
the available displayed messages and a description and
definition of each message.
Table 21
DOOR LIMIT MESSAGES
Table 22 below lists the door limit messages associated
with the control system. Included in this table are the
displayed messages and a description of each mes-
sage.
Table 22
Displayed
Message
Description
Door Held Open Door held open. Input termi-
nal shown in lower right of
display.
Door Is Closing Door is closing.
Door Is Open Door open in full-open posi-
tion.
Door Is Opening Door is opening.
Door Is Stopped Door is stopped — controller
waiting for next incoming
command.
Emergency Jog Door travel possible in jog
mode only — all safety and
limits ignored.
Emergency Stop One of the emergency stops
is activated.
Error Jog Only Door fault — door travel in jog
mode only.
Jog Mode Manual door operation — jog
mode only. To enter and exit
jog mode, push stop and
down arrow simultaneously.
Locked Closed Door locked in closed posi-
tion. Input terminal shown in
lower right corner of display.
Partial Open
Position
Door in partial-open
position.
Rytec Door Type Cycle count.
Set Limits Start limit set-up procedure.
▼
▲
▼
▲
Displayed
Message
Description
Automatic Denotes controller in auto-
matic mode.
Jog Mode Denotes controller in jog
mode. To enter and exit jog
mode, push stop and down
arrow simultaneously.
Displayed Message Description
! Set Limits ! Limit set-up initialization.
→ ●To Begin Initialize limit setting.
→Ú To Closed Pos. Close limit set-up.
→Ú To Open Pos. Open limit set-up.
→Ú To Part. Pos. Partial limit set-up.
Close Limit Set Close limit setting.
Hold ● If Ok Save limit setting.
Open Limit Set Open limit setting.
Part. Limit Set Partial limit setting.
