MISCELLANEOUS MESSAGES—PROGRAMMABLE TEXT MESSAGES
51
PROGRAMMABLE TEXT MESSAGES
Table 25 below lists the programmable text messages
associated with the control system. Included in this
table are the available strings and their description.
Table 25
Text Message
Number
Description
1 (Open) Open door.
(Terminals 200 and 201)
2 (Open — ACL1) Open/close with ACL1 timer.
(Terminals 210 and 212)
3 (Open — ACL2) Open/close with ACL2 timer.
(Terminals 230 and 233)
4 (A/A Op — C1) Door open and close.
(Terminals 210 and 211)
5 (Close) Close door.
(Terminals 200 and 202)
6 (Stop) Stop door.
(Normally closed: remove
jumper terminals 200 and
203)
7 (Photoeye — Fr) Front photo eye. (Terminal
222)
8 (Photoeye — Rr) Rear photo eye. (Terminal
232)
9 (Photoeye — Aux) Auxiliary photo eye.
10 (Door Ajar) Breakaway bottom bar
disconnected from side
column. (Terminal 271)
11 (Blower On) Freezer blower on.
12 (Blower High) Freezer blower on high.
13 (Blower Auto) Freezer blower on auto.
14 (Heater St.1) Freezer heater stage 1 or
heat lamps on.
15 (Heater St.2) Freezer heater stage 2 on.
16 (Heater St.3) Freezer heater stage 3 on.
17 (Heater Auto) Freezer heater on auto.
18 (HW Interlock) Freezer hard door interlock.
To Next Page
