SYSTEM PARAMETERS—REVERSING EDGE CIRCUIT FAULT CODES
43
REVERSING EDGE CIRCUIT FAULT CODES
Table 14 below lists the fault codes associated with the
reversing edge circuit. Included in this table are the
available fault codes, a description of each fault code,
and the suggested corrective action to clear the fault.
(The door is in the error jog only mode.)
Table 14
Fault Code
(Displayed Message)
Description Corrective Action
F.361
(Edge Trip)
(edge trip)
Reversing edge tripped.
1. Bottom edge of door made contact with
object in door opening
2. Short circuit in reversing edge wiring
3. Pressure switch faulty or not adjusted
1. Reset control system
2. Check and repair wiring
3. Check and adjust switch
NOTE: Ohm reading on terminals
272 and 283 should read
8.2K or 8200 ohms.
All wireless units use a 8.2K
ohm resistor.
F.363
(Edge Open)
Reversing edge circuit open.
1. Reversing edge wiring disconnected
2. Reversing edge cable in the bottom bar
may be cut or damaged.
3. Reversing edge resistor is wrong value
or missing
Check all parts of reversing edge circuit
including resistor. Make any necessary
repairs or adjustments. Verify proper
operation of reversing edge after all
repairs and adjustments are made. Ohm
reading is ohms at terminals.
NOTE: All resistors are 8.2K ohms.
Terminals 272 and 273.
